Product
Type:
|
Vacuum
Tube Push - Pull Power Amplifier Mono Block
|
|
Pre-Amp/Input
Tubes:
|
12BH7A
x 1
|
|
Driver
Tubes:
|
6CG7
x 1
|
|
Output
Tubes:
|
Svetlana
KT88 x 6
|
|
Rectifier
:
|
Ultra
Fast Recovery Diode
|
|
Coupling
Capacitors:
|
Hovland
Musicap
|
|
Output
Transformer:
|
Silk
P-1250 Dual Bobbin
|
|
Output
Power:
|
150
watts/CH class AB1, 200 watts peak power
|
|
Overall Gain:
|
27dB
|
|
Negative
Feedback:
|
11dB
|
|
Frequency
Response:
|
10-80,000Hz
(-3dB)
|
|
THD:
|
1.5%
at rated power
|
|
S/N
ratio:
|
below
88dB
|
|
Size:
|
(W)
43 x (D) 28 x (H) 25 cm.
|
|
Weight:
|
Approx
25 kg.
|
|
Direct
From Factory Price :
|
Please
Contact.
|
|
