Product
Type:
|
Stereo Vacuum
Tube Integrated Power Amplifier with 5 RCA Input
|
|
Pre-Amp/Input
Tubes:
|
6N1P x 2
|
|
Driver Tubes:
|
5687 x 2
|
|
Output Tubes:
|
2A3 Electro
Harmonix. x 2
|
|
Rectifier
:
|
5U4G
|
|
Filter Capacitor:
|
100+100uF
Audiophile Grade
|
|
Filter Choke:
|
Low Loss
10H/200mA
|
|
Coupling
Capacitors:
|
Hovland
Musicap
|
|
Signal Resistors:
|
Kiwame Carbon
Film type
|
|
Output Transformer:
|
SILK S-325(Fi)
Transformer 3.0K EI M6 core
|
|
Output Power:
|
3.5 watts/CH
class A1 design
|
|
Frequency
Response:
|
10-100,000Hz
(-3dB) at full power
|
|
Input Sensitivity:
|
0.45V for
full power output (at maximum volume gain)
|
|
Overall
Gain:
|
33dB
|
|
THD + noise:
|
Less than
5% at rated power
|
|
S/N ratio:
|
below 88dB
|
|
Size:
|
(W) 43 x
(D) 37 x (H) 20 cm.
|
|
Weight:
|
Approx 18kg.
|
|
Direct From
Factory Price :
|
Please Contact.
|
